Envirotech Façade Solutions has started its design process with a blank sheet. Instead of short cutting the process and utilising the traditional shopfront suites of the 1960’s, EFS has instead designed a range of commercial suites which meet or exceed todays’ requirements, codes and architectural trends.
The 101SGF system is a 101.6mm (4″) x 60mm single glazed front glazed system is designed to be used in most commercial and semi commercial applications. This suite also caters nicely for those looking for a more robust, cleaner looking design option for up-market housing applications. The front glazed system not only allows for a cleaner more modern looking system than its centre glazed counter-part but also provides the added benefits of a higher performance drainage system as well as greater living room or office space.
This system has a glazing pocket opening width of 21mm, which allows for the use of glass up to 13.52mm thick while still providing a minimum glass edge cover of up to 12mm ensuring compliance to AS1288. These design features translate to designers and fabricators having the ability to glaze thicker and therefore larger pieces of energy efficient glass than many of the other suites currently on offer to the market.
This new design has a male and female mullion which allows for a glass installation clearance of at least
6mm while using up to 13.52mm glass, significantly reducing the risk of scratching the frame or damaging
the glass during glass installation.
From a performance perspective these features mean that designers need not compromise their designs in order to achieve the latest performance requirements for thermal, acoustic, structural and water ratings.
The EFS 101SGF system is complimented by its ability to seamlessly integrate with our ‘AC-35’ and ‘AC-50’ awning/casement window systems and sliding door system to name just a few.
Please contact our friendly sales or technical staff for help with your design requirements so that we may customise a solution for your next project.
